CS-4Z350
Changsheng
Plywood Ring Debarker 4 Feet Hydraulic Machine
plywood machine : 4 feet log debarker machine
This machine is used to debarking the skin and making round the log before peeling
1.This machine adopts rotary cutting principle of non-chuck rotary lathe
2.The hydraulic pressure drive into the constructions, can quickly and effectively remove bark and complete log the round work
3.This machine reasonable structure, easy operation and maintenance
4.This machine equipment performance is stable, less wearing parts, long life
5.Artificial technical requirements are not high,in the normal peeling the error range in ± 0.1mm
6.This machine's wood loss rate achieve 1%,saving timber resources
7.This machine is suitable for the Poplar, Eucalyptus etc
| NAME | UNIT | PARAMETER |
| Power of Single Roller Motor | KW | 7.5 |
| Power of Double Roller Motor | KW | 11 |
| Power of Pumping Station | KW | 5.5 |
| Total Power | KW | 24 |
| Single Roller Reducer | 250 | |
| Double Roller Reducer | 350 | |
| Peeling Knife Size | MM | 1500*130*12.7 |
| Max. Log Length | MM | 1500 |
| Max. Log Diameter | MM | 700 |
| Min. Last Core Diameter | MM | 80 |
| Machine Size | MM | 4000*1900*1400 |
| machine weight | KG | 2600 |
| Machinable tree species | Poplar, Eucalyptus etc. |
All our plywood machines can be customized according to your production requirements
Packaging | |
| Weight | 2600KG |
| Size | 4000*1900*1400 |
| Packaging Details | If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
