CS-SB2618-3
Changsheng
8456920000
Eight Feet Core Veneer Vacuum Stacker
| ITEM | UNIT | PARAMETER |
| Fan Power | KW | 3 *10 |
| Veneer Conveyor Power | KW | 2.2*1 |
| Stack Transportation Power | KW | 2.2*4 |
| Unqualified Veneer Conveyor Power | KW | 1.5*1 |
| The Secondary Transportation Power | KW | 2.2*1 |
| Hydraulic Lift Platform Power | KW | 4*2 |
| Veneer Pusher Motor | KW | 2.6(servo motor)*2 |
| Total Power | KW | 57.9 |
| Stacking Width | MM | 1800 |
| Stacking Length | MM | 2600 |
| Veneer Thickness | MM | 0.8-3.0 |
| Max Stacking Height | MM | 1200 |
| Max Stacking Speed | M/MIN | 100 |
| Minimum Diameter of Detection Hole | MM | 50 |
| Grading Number | 3 | |
| Stacking Number | 2 | |
| Lifting Method | Hydraulic | |
| Dimension | MM | 14500*3300*2900 |
| Weight | KG | 6200 |
High speed stacking, the max speed can reach 100 m/min
Fully automatic, automatic transmission, automatic veneer grading, and automatic stacking.
Stable running, optimal design and reliable spare parts supplier guarantee the stable running of this machine
Eight Feet Core Veneer Vacuum Stacker
| ITEM | UNIT | PARAMETER |
| Fan Power | KW | 3 *10 |
| Veneer Conveyor Power | KW | 2.2*1 |
| Stack Transportation Power | KW | 2.2*4 |
| Unqualified Veneer Conveyor Power | KW | 1.5*1 |
| The Secondary Transportation Power | KW | 2.2*1 |
| Hydraulic Lift Platform Power | KW | 4*2 |
| Veneer Pusher Motor | KW | 2.6(servo motor)*2 |
| Total Power | KW | 57.9 |
| Stacking Width | MM | 1800 |
| Stacking Length | MM | 2600 |
| Veneer Thickness | MM | 0.8-3.0 |
| Max Stacking Height | MM | 1200 |
| Max Stacking Speed | M/MIN | 100 |
| Minimum Diameter of Detection Hole | MM | 50 |
| Grading Number | 3 | |
| Stacking Number | 2 | |
| Lifting Method | Hydraulic | |
| Dimension | MM | 14500*3300*2900 |
| Weight | KG | 6200 |
High speed stacking, the max speed can reach 100 m/min
Fully automatic, automatic transmission, automatic veneer grading, and automatic stacking.
Stable running, optimal design and reliable spare parts supplier guarantee the stable running of this machine
